CFD Fluid Dynamics Simulations With Solidworks (Cooling Performance of Electric Motor)

What Will You Learn?

• Set up a complete CFD cooling simulation in SolidWorks
• Model fluid flow and heat transfer in an electric motor housing
• Apply correct inlet, outlet, and heat source boundary conditions
• Analyze temperature, flow, and cooling performance
• Use cut plots, surface plots, flow trajectories, and goal plots
• Compare different designs by changing heat load, flow rate, and channel size
• Understand why a cooling design works or fails
